Cooler Master Elite 500 230V - V4 - Power Supply Unit, 500W, 24-pin ATX, Black

Delivery
Payment options
Our advantages
  • — Garantía: 3 Years Warranty
  • — Devolución y cambio hasta 30 días
  • — Mejor precio

Power Up

The Elite - v4 series power supply unit is a dependable choice for entry level PC builders and office work systems. The quiet 120mm fan, 80 PLUS White EU 230V efficiency, and 3 year warranty deliver a PSU that provides function and resilience you can count on. It's the perfect option for work horse systems stored and operated in less than ideal conditions and climates. This PSU has been engineered for reliability with a focus on reducing random shutdowns in conditions where power sources are inconsistent and unstable, making it ideal for locations prone to experience brown outs. The Elite - v4 is a complete solution, offering performance and stability at an affordable price.

Active PFC + Forward Topology Design

A power supply unit works by taking power directly from the wall or other fixed power source, converting it to the correct output required by the connected components, and then distributing that power to said components. If any part of this process is interrupted or executed poorly, the connected system components and the PSU itself could be damaged. Active PFC uses a circuit to correct power factor leading to reduced total harmonics, corrected AC input voltage, and increased overall efficiency output.

High Temperature Resistance

The new Elite - v4 has a maximum operating temperature of 40°C. That's at the level of many 80 Plus certified power supply units on the market today. This higher operating temperature allows you to power your system safely in warmer environments without having to worry about your system overheating or shutting off unexpectedly. The higher heat resistance also reduces temperature based wear, increasing the lifespan of the unit by a noticeable amount.

Peak Power Tolerance

This power supply unit can push out an additional 50W above maximum load for up to 10 seconds before turning off. This will allow your system a chance to save data and complete current processes in the event of output surge or overloading. While it may not be a feature you'll actively need all the time, it can be extremely useful in an emergency scenario.

80 Plus White EU 230V Efficiency

The efficiency of your power supply unit is important because it directly affects your system's performance and your power bill. The efficiency rating does not reflect the quality or reliability of a PSU. It only reflects the unit's ability to move power from the wall to your components. The higher a PSU's efficiency is, the lower the total amount of power it needs to power your system. The Elite - v4 has a guaranteed typical efficiency of 85%

Durable, Reliable, And Safe

The Elite - v4 will perform consistently in whatever environment you throw at it whether it's high altitudes above 5000 meters or ultra humid settings like a tropical rain-forest. This unit was designed for work systems meant to be used in extreme conditions with challenging temperatures. Do whatever you need to do wherever you need to do it without letting your hardware limit your goals.

PSU Calculator

Need help choosing the right power supply for your system? Try out our easy to use, comprehensive PSU calculator.

Manufacturer site

Main
Brand
Cooler Master
Warranty
3 Years Warranty
Design
Diámetro de ventilador
12 cm
Interruptor de encendido/apagado integrado
Si
Número de ventiladores
1 fan(s)
Tipo de enfriamiento
Active
Color del producto
Black
Operational conditions
Intervalo de temperatura operativa
0 - 40 °C
Packaging data
Altura del paquete
96 mm
Ancho del paquete
213 mm
Profundidad del paquete
195 mm
Tipo de embalaje
Box
Performance
Certificación
TUV / cTUVus / CE / BSMI / FCC / EAC / \nRCM / KCC / CCC / CB
Factor de forma de fuente de alimentación (PSU)
ATX
Tecnología de rodamientos
Funda
Tiempo medio entre fallos
100000 h
Utilizar con
PC
Versión ATX
2.41
Ports & interfaces
Alimentador de energía para tarjeta madre
24-pin ATX
Conector de alimentación EPS (4+4 pines)
Si
Conectores de poder (4 pin) periferales (Molex)
3
Conectores de poder PCI Express (6 + 2 pin)
2
Número de conectores de energía SATA
5
Tipo de cableado
Non-Modular
Power
Corrección del factor de potencia tipo (PFC)
Active
Corriente de entrada
5 A
Corriente máxima de salida (+12V)
38 A
Corriente máxima de salida (+3.3V)
14 A
Corriente máxima de salida (+5V)
16 A
Corriente máxima de salida (+5Vsb)
3 A
Corriente máxima de salida (-12V)
0.3 A
Eficiencia
85%
Frecuencia de entrada AC
50/60 Hz
Funciones de protección de poder
Sobretensión, Sobrevoltaje, Bajo voltaje
Margen de retardo de la señal Power Good
100 - 500 ms
Potencia combinada (+12 V)
500 W
Potencia combinada (+5 V)
110 W
Potencia combinada (+5 VSB)
15 W
Potencia combinada (-12V)
3.6 W
Potencia combinada (3,3 V)
110 W
Tiempo de espera
14 ms
Voltaje de entrada AC
200 - 240 V
Weight & dimensions
Altura
86 mm
Ancho
150 mm
Profundidad
140 mm

Búsqueda automática de vídeos por nombre de producto (el resultado puede no coincidir con el producto anunciado en nuestro sitio web).

Adicional (mmo_80166649_1594642262_8687_7960.pdf, 133 Kb) [Descargar]
