MSI MAG A550BN - 550W Power Supply, 80 Plus Bronze, Black

Delivery
Payment options
Our advantages
  • — Warranty: 1 Year Warranty
  • — Return and exchange up to 30 days
  • — Best price
Find similar

MAG A550BN provides players with a safe, reliable, and efficient entry-level power supply option. Its core features include 80 PLUS Bronze certification, DC to DC circuit design, 12V single rail, active PFC, and low-noise fan. The MAG A550BN will be one of the best choices for players who are just getting started with looking into DIY computers. After installation, gamers can immediately enjoy a reliable performance experience without additional settings.

80 PLUS BRONZE CERTIFIED
The efficiency of your power supply directly influences your system’s performance and your power consumption. The 80 PLUS BRONZE certification promises lower energy consumption and higher efficiency.

120MM LOW NOISE FAN
The fan’s sleeve bearing reduces the noise generated while maintaining excellent heat dissipation.

DC TO DC CIRCUIT DESIGN
Adopted DC-DC circuit design reduces the instability of output voltage, and ads stability to the supply of power.

COMPREHENSIVE CIRCUIT PROTECTION
Supports OCP, OVP, SCP, OPP, OTP protection
mechanisms and provides comprehensive protection.

5-YEAR LIMITED WARRANTY
The MAG A550BN is proudly backed by a 5-year limited warranty, guaranteeing long term reliable operation.



Manufacturer site

Main
Brand
MSI
Warranty
1 Year Warranty
Product code
4719072849603
EAN/UPC code
4719072849603
Design
360° rotational base
No
Cooling type
Active
Fan diameter
12 cm
Number of fans
1 fan(s)
On/off switch
Yes
Product colour
Black
Features
24/7 operation
No
4K Ultra HD upscaling
No
64-bit computing
No
Logistics data
Harmonized System (HS) code
84733020
Other features
2.5 mm connector
No
3.5 mm (1/8-inch) in
No
64-bit computing
No
Performance
2.4 GHz
No
360 camera support
No
360 video player support
No
3D
No
5 GHz
No
Power supply unit (PSU) form factor
ATX
Purpose
PC
Ports & interfaces
ATX power connector (20+4 pin)
ATX Power connector (24-pin)
Cabling type
Modular
EPS power connector (4+4 pin)
Yes
EPS power connector (8-pin)
No
Motherboard power cable length
60 cm
Motherboard power connector
20+4 pin ATX
Number of SATA power connectors
5
PCI Express power connectors (6+2 pin)
2
Peripheral (Molex) power connectors (4-pin)
2
Power
80 PLUS certification
80 PLUS Bronze
AC input frequency
50/60 Hz
AC input voltage
100 - 240 V
Combined power (+12V)
546 W
Combined power (+3.3V)
110 W
Combined power (+5V)
110 W
Combined power (+5Vsb)
12.5 W
Combined power (-12V)
3.6 W
Efficiency
85%
Max output current (+12V)
45.5 A
Max output current (+3.3V)
20 A
Max output current (+5V)
20 A
Max output current (+5Vsb)
2.5 A
Max output current (-12V)
0.3 A
Maximum input current (@110V)
8 A
Maximum input current (@220V)
4 A
Power Factor Correction (PFC) type
Active
Power protection features
Over current, Over power, Over voltage, Overheating, Short circuit
Total power
550 W
Weight & dimensions
Depth
140 mm
Height
86 mm
Width
150 mm
Automated video search by product name (the results maybe not the some as product in our store).

Manual (mmo_93221898_1645088726_8451_10555.pdf, 1,056 Kb) [Download]

Additional (mmo_93221898_1637930874_8414_22244.pdf, 642 Kb) [Download]
