MSI PRO B860M-A WIFI - Motherboard, Intel B860 LGA 1851 (Socket V1), micro ATX
4711377286565
Delivery
Payment options
Our advantages
- — Warranty: 1 year warranty
- — Return and exchange up to 30 days
- — Best price
Find similar
- Processor socketLGA 1851 (Socket V1)
- Compatible processor seriesIntel Core Ultra (Series 2)
- Motherboard chipsetIntel B860
- Supported memory typesDDR5-SDRAM
- Number of memory slots4
- Motherboard form factorMicro ATX
- All features
Advanced Engineering
MSI has extensive experience in developing high-performance motherboards. They select the best circuits and components to create devices that can operate reliably even in the most extreme conditions.
Enhanced Performance
High-performance MSI motherboards are packed with advanced features and technologies that will benefit any user, be it a gamer, professional or PC enthusiast.
Extreme Stability and Compatibility Testing
MSI tests memory modules from the most popular brands, including Corsair, Crucial, Kingston, G.Skill and many others, to ensure maximum compatibility with its products and improve overclocking potential.
Main
Brand
MSI
Warranty
1 year warranty
Product code
4711377286565
EAN/UPC code
4711377286565
BIOS
ACPI version
6.5
BIOS memory size
256 Mbit
BIOS type
UEFI AMI
System management BIOS (SMBIOS) version
3.7
Expansion slots
1st M.2 highest PCI Express generation
5.0
1st M.2 largest key size
2280
2nd M.2 highest PCI Express generation
4.0
2nd M.2 largest key size
2280
3rd M.2 highest PCI Express generation
4.0
3rd M.2 largest key size
2280
Number of M.2 (M) slots
3
PCI Express x16 (Gen 4.x) slots
3
PCI Express x16 (Gen 5.x) slots
1
Features
Audio chip
Realtek ALC897
Audio output channels
7.1 channels
Motherboard chipset
Intel B860
Motherboard chipset family
AMD
Motherboard form factor
Micro ATX
Product colour
Black
Internal I/O
CPU fan connector
Yes
Number of CPU fan connectors
1
Number of RGB LED pin headers
3
Number of SATA III connectors
4
Number of water pump connectors
1
RGB LED pin header
Yes
Total number of SATA connectors
4
USB 2.0 connectors
4
USB 3.2 Gen 1 (3.1 Gen 1) connectors
4
USB 3.2 Gen 2 (3.1 Gen 2) connectors
1
Memory
ECC сompatibility
Non-ECC
Maximum internal memory
256 GB
Memory channels
Dual-channel
Memory slots type
DIMM
Number of memory slots
4
Supported memory clock speed (max)
8800 MHz
Supported memory clock speeds
4800,6400,8800 MHz
Supported memory types
DDR5-SDRAM
Network
Bluetooth
Yes
Bluetooth version
5.4
Ethernet interface type
5 Gigabit Ethernet
Ethernet LAN
Yes
Top Wi-Fi standard
Wi-Fi 7 (802.11be)
Wi-Fi
Yes
Wi-Fi standards
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Processor
Maximum internal memory supported by processor
256 GB
Processor manufacturer
Intel
Processor socket
LGA 1851 (Socket V1)
Compatible processor series
Intel Core Ultra (Series 2)
Rear panel I/O ports
Ethernet LAN (RJ-45) ports
1
HDMI ports quantity
1
HDMI version
2.1
USB 2.0 ports quantity
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
1
Storage controllers
Number of HDDs supported
4
Number of storage drives supported
7
RAID levels
0, 1, 5, 10
RAID support
Yes
Supported storage drive interfaces
M.2, Micro SATA III
Supported storage drive types
HDD & SSD
System requirements
Windows operating systems supported
Windows 11 x64
Weight & dimensions
Depth
243.8 mm
Width
243.8 mm
