Mox Plug MX-S20 - HDMI Extender, 60m
- — אחריות: שנה אחריות
- — החזרה והחלפה עד 30 יום
- — המחיר הטוב ביותר
The Extender uses single cat5e or cat6(recommended) cables instead of HDMI cable to transmit high definition signal up to 60 meters, cutting down the cost. The Extender is designed to supply for long distance transmission of high definition signal.
Specification
Length of CAT-6/CAT-5E cable between TX and RX: Up to 60 meters
HDMI Input: 1080p/1080i/720p/576p/576i/480p/480i
HDMI Output: 1080p/1080i/720p/576p/576i/480p/480i
Max bandwidth: 150MHz
Max baud rate: 4.5Gbps
Input video signal: 0.5~1.5Volts p-p
Output DDC signal: 5Volts p-p (TTL)
Input HDMI cable distance: ≤10m AWG26 HDMI standard cable
Output HDMI cable distance: ≤15m AWG26 HDMI standard cable
TX Max working current: 300mA
RX Max working current: 300mA
Power adapter format: AC Input (50HZ, 60HZ) 100V-240V; Output: DC5V/1A
Operating Temperature range: (-15 to +45℃)
Operating Humidity range: 5 to 90%RH (No Condensation)
Dimension (L x W x H): 52x38x17 (mm)
TX Weight: 24.5g
RX Weight: 24.9g
