TP-Link TL-SG1016 - Network Switch, Unmanaged, Gigabit Ethernet (10/100/1000), 1U, Black
TP-Link TL-SG1016 - Network Switch, Unmanaged, Gigabit Ethernet (10/100/1000), 1U, Black
‎ ‍544‍

TP-Link TL-SG1016 - Network Switch, Unmanaged, Gigabit Ethernet (10/100/1000), 1U, Black

CA-310152
אספקת הזמנה
אפשרויות תשלום
היתרונות שלנו
  • — אחריות: שנה אחריות
  • — החזרה והחלפה עד 30 יום
  • — המחיר הטוב ביותר
חיפוש מוצרים דומים
  • כמות יציאות RJ-45 Ethernet16
  • סוג יציאות רשתGigabit Ethernet 10/100/1000
  • סוג מתגלא מנוהל
  • גודל פיזי של הכונן1U
  • כל התכונות

What This Product Does
The TL-SG1016 Gigabit Ethernet Switch provides you with a high-performance, low-cost, easy-to-use, seamless and standard upgrade to improve old network to 1000Mbps network. All 16 ports support auto MDI/MDIX, no need to worry about the cable type, simply plug and play. Moreover, with the innovative energy-efficient technology, the TL-SG1016 can save power consumption, making it an eco-friendly solution for your business network.

TP-Link Green Technology
This new generation TL-SG1016 Gigabit Switch features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status to limit the carbon footprint of your network. It also complies with the EU’S RoHS, prohibiting the use of certain hazardous materials. Besides, most packaging material can be recycled.

High Performance
All 16 ports are Gigabit RJ-45 ports which can provide large file transferring and also be compatible with 10Mbps and 100Mbps Ethernet devices. Featuring non-blocking switching architecture, TL-SG1016 forwards and filters packets at full wire-speed for maximum throughput. With 10KB Jumbo frame, the performance of large files transfers is improved significantly. And IEEE 802.3x flow control for Full Duplex mode and backpressure for Half Duplex mode alleviate the tra­ffic congestion and make The TL-SG1016 work reliably. It’s a perfect choice to update your network to Gigabit while protecting your previous investment properly.

Easy to Use
The auto features of this gigabit switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminates the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (10, 100, or 1000 Mbps) and intelligently adjusts for compatibility and optimal performance.


Manufacturer site

כללי
מותג
TP-Link
רשת
2G
לא
3G
לא
4G WiMAX
לא
אוטומטי MDI/MDI-X
לא
שליטת שידור בזמן סערה
לא
שן כחולה Bluetooth
לא
תמיכה 10G
לא
Data transmission
Forwarding rate
23.8 Mpps
Jumbo frames
10000
Jumbo frames support
Store-and-forward
כן
טבלת כתובות MAC
8000 כניסות
קיבולת החלפה (Switching)
32 Gbit/s
Management features
סוג מתג
לא מנוהל
תמיכת איכות השירות (QoS)
כן
אבטחה
Access Control List (ACL)
DHCP features
DHCP client, DHCP server, DHCP snooping
IGMP snooping
Password protection
כן
אלגוריתמי אבטחה נתמכים
802.1x RADIUS
ביצועים
2.4 GHz
לא
3D
לא
Fanless
כן
חבילות מידע
Rack mount kit
כן
כבלים כלולים
AC
יציאות וממשקים
כמות יציאות RJ-45 Ethernet
16
סוג יציאות רשת
Gigabit Ethernet 10/100/1000
מאפיינים
24/7 operation
לא
משקל ומידות
גובה
44 mm
עומק
180 mm
רוחב
440 mm
נתונים לוגיסטיים
Harmonized System (HS) code
85176990
עיצוב
360° rotational base
לא
גודל פיזי של הכונן
1U
הסמכה
FCC, CE, RoHS
התקנה במארז
כן
מחווני LED
צבע המוצר
Black
צריכת חשמל
AC input frequency
50/60 הרץ
AC input voltage
100 - 240 V
Power consumption (max)
10.44 W
צריכת חשמל
9.26 W
רשת
10G support
לא
4G
לא
Auto MDI/MDI-X
כן
Auto-negotiation
כן
Cable types supported
Cat3, Cat4, Cat5, Cat5e
Copper ethernet cabling technology
10BASE-T, 100BASE-TX, 1000BASE-T
Ethernet LAN data rates
10,100,480,800,1000 Mbit/s
Flow control support
כן
Full duplex
Head-of-line (HOL) blocking
כן
IP routing
כן
Networking standards
IEEE 802.1p, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Policy-based routing
כן
Port mirroring
כן
VLAN support
כן
תכונות נוספות
2.5 mm connector
לא
3.5 mm (1/8-inch) in
לא
תנאים תפעוליים
בזבוז חום (חוסר ניצול אנרגיית חום)
35.6 BTU/h
טווח טמפרטורות אחסון (T-T)
-40 - 70 ?C
טווח טמפרטורת פעולה (T-T)
0 - 40 ?C
טווח לחות יחסית בפעולה
10 - 90 %
טווח לחות יחסית לאחסון
5 - 90 %
חיפוש וידאו אוטומטי לפי שם של המוצר (ייתכן שהתוצאה לא תואמת למוצר המפורסם באתרינו).

נוסף (mmo_79344091_1591185341_8384_17407.pdf, 748 Kb) [הורד]

הוראות (mmo_79344091_1591185330_3944_10738.pdf, 366 Kb) [הורד]
