VScom 200E - v4 PCIex Card, 2x RS-232
- — אחריות: שנה אחריות
- — החזרה והחלפה עד 30 יום
- — המחיר הטוב ביותר
The VScom 200E PCIex is a smart 2-ports PCI Express serial card, designed for industrial automation and POS/ATM applications. VScom 200E PCIex runs with all major operating systems. The serial ports equipped with 256 byte FIFOs support data rates up to 500kbps and use full modem control signals for compatibility with a wide range of serial devices. The ports also allow every non-standard bitrate up to 500kbps. On-chip s/w and h/w flow control ensure quick reaction and so error free data transmission at high baud rates. Serial ports are ESD and surge protected.
The board can be plugged into Standard Height and Low-Profile PC cases. Mounted is the standard bracket, Low Profile is placed in the box. Also included is the adapter cable DB25F to 2 x DB9M (Pins and signals like on a PC).
Features
- 2 x RS232 ports, ESD and surge protected
- 500 kbps max. baud rate for fast data transfer
- 256-Byte FIFO and on-chip H/W, S/W flow control
- Compatible with PCIex x1, Plug and Play
- Low Profile form factor, STD and LP brackets
- Wide temp range -40° to +65°C
- Drivers for Windows XP / 7 / 8 / 10 and Linux
- Adapter cable 2 x DB9M included
Specifications
| Ports | 2x RS232 (RxD, TxD, RTS, CTS, DTR, DSR, DCD, RI) |
| UART | 2x 16C850 (256 Byte FIFO, ON-Chip HW-/SW-Flow Control) |
| LED | LED for TxD and RxD on each port |
| Address | Plug and Play |
| Interrupts | PCI Plug and Play, only one interrupt per card |
| Speed | 50bps – 500 kbps all standard bitrates available also non-standard bitrates possible (e.g. 500kbps) |
| Bus interface | PCI Express x1 |
| Connectors | 1x DB25F, adapter cable 2 x DB9 male |
| Low Profile | Extra bracket added for Low Profile case mounting |
| Temperature | −40°C – +65°C |
| FIFO | adjustable FIFO length, 1 up to 256 Bytes separate adjustable Rx and Tx |
| Handshake | RTS / CTS DTR / DSR Xon / Xoff all handshake automatic on Chip |
| Speed | 50 bps up to 500 kbps all Baudrates possible |
| Access | high speed access via Memory |
| UART | UART emulation 16850 |
| Windows 2000 up to 10 | High performance serial driver, x86 and x64 Editions |
| Linux | Kernel 3.0 and up: built-in support |
| Card Size | L65mm × H67mm |
| Card Weight | 40g |
| Cable Weight | 150g |
| Box Size | L165mm × W153mm × H62mm |
| Box Weight | 210g |
| Declarations | CE, FCC |
| EMI | EN 55022 Class B 47 CFR FCC Part 15 Subpart B |
| EMS (EN 55024) | EN 61000-4-3: Radiated RFI EN 61000-4-4: Electrical Fast Transient EN 61000-4-5: Surge EN 61000-4-6: Induced RFI EN 61000-4-8: Power Frequency Magnetic Field EN 61000-4-11: Power supply dips |
| ESD | EN 61000-4-2 4kV contact 8kV air for Serial Ports |
| Packing list | VScom 200E v4 PCIex card Adapter cable 2 Ports RS232 DSUB 9 male Extra bracket for Low Profile form factor |
